PP/PET Non-Woven Geotextiles
- .Material: PP (Polypropylene), Virgin PET(Polyester), Recycle PET
- Gram Weight Range 100~1200g/M2
- Colour:White,Blue,Green,Grey,Black.
- Width: 1m-6m
- Product description: PP/PET Non-Woven Geotextiles is Synthetic Staple Needle punched Nonwoven Geotextile made of PET or PP. comes in 6m wide rolls with 100-800g/m2. Offering specialized properties including high break str
Product introduction
PP/PET short fiber/continuous filament nonwoven geotextile
Introduction:
Filament needle punched nonwoven geotextile using all new polyester resin spunbonded continuous filament needle punched geotextiles are manufactured by the extrusion of fibers which are then laid down on a manufacturing "bed" and then needle punched from both top and bottom to entangle the fibers to produce a dimensionally stable geotextile.
|
Material |
PP (polypropylene), Virgin PET(polyester), recycle PET |
|
Techinics |
thermally bonded and needle punched |
|
Specification |
Usually 100g/m2 to 1200g/m2 or as your demand |
|
Width |
1m to 6m(as you demand) |
|
Length |
100m(as you demand) |
|
Colour |
White,Green,Grey,Black.etc |
|
Packing |
PE film and woven cloth, paper core inside if you ask. |
Functions
1.Separation
The isolation of the railway dregs and the roadbed, roadbed and the soft base,
surface of the airdrome and parking lot and the groundsill, different dam
materials. It isolates the soil and the gravel of two kinds different
granule pathway from the
groundsill or other buildings.
2.Reinforcement
The highway, railway, soil-stone dam, breakwater, airport, backfill soil of
retaining wall, slope protection, etc in which distributes the earth stress,
prevents the side-displacement of the earth body and improves the earthbody
stability.
3.Protection
It prevents the bank from being washed out, protects the bank and the
bottom, prevents the water and soil from being washed away
Short fiber nonwoven geotextile technical data
|
Item |
Art No. |
1 |
2 |
3 |
4 |
5 |
6 |
7 |
8 |
9 |
10 |
11 |
|
Unit weight, g/m2 |
100 |
150 |
200 |
250 |
300 |
350 |
400 |
450 |
500 |
600 |
800 |
|
|
Weight tolerance, % |
-8 |
-8 |
-8 |
-8 |
-7 |
-7 |
-7 |
-7 |
-6 |
-6 |
-6 |
|
|
Thickness, ≥mm |
0.9 |
1.3 |
1.7 |
2.1 |
2.4 |
2.7 |
3.0 |
3.3 |
3.6 |
4.1 |
5.0 |
|
|
Break strength, ≥kN/m |
2.5 |
4.5 |
6.5 |
8.0 |
9.5 |
11.0 |
12.5 |
14.0 |
16.0 |
19.0 |
25.0 |
|
|
CBR burst strength, ≥kN |
0.3 |
0.6 |
0.9 |
1.2 |
1.5 |
1.8 |
2.1 |
2.4 |
2.7 |
3.2 |
4.0 |
|
|
Tear strength, ≥kN |
0.08 |
0.12 |
0.16 |
0.20 |
0.24 |
0.28 |
0.33 |
0.38 |
0.42 |
0.46 |
0.60 |
|
|
Width tolerance, % |
-0.5 |
|||||||||||
|
Break elongation, % |
25-100 |
|||||||||||
|
EOS O90, mm |
0.07-0.2 |
|||||||||||
|
Vertical permeability coefficient, cm/s |
K×(10-1-10-3)K=1.0-9.9 |
|||||||||||
Features & benefits
- Mass per unit areas range from 100g to 800g/m2 to guarantee an available product for every application (heavier products may be available by special order)
- Superior chemical resistance in even the most aggressive environmental applications
- Continuous long fibers needle punched together to form a sturdy fabric capable of withstanding construction installation stresses
- Contains additives for maximum UV resistance
